Description
FAP40T Commercial Pendant Speaker
- 16W 70V Commercial Pendant Speaker
- 8W Transformer Bypass for Flexible System Design
- Tuned & Ported Enclosure for Extended Bass Response
- Press-Fit Architectural Grille with Low Profile Design
- Includes Tile Bridge for Easy Installation
Product Overview
The FAP40T is a high-performance 4″ commercial pendant speaker engineered for clear voice
intelligibility and smooth music reproduction in retail, hospitality, education, and institutional
environments. Designed for both system integrators and architects, it delivers exceptional
performance in a compact footprint while maintaining a clean, contemporary appearance
Key Performance Features
- 16W internal transformer with multiple tap selections
- 8W transformer bypass setting
- Integrated rotary tap selector for easy system tuning
- Tuned & ported enclosure for enhanced low-frequency response
- Natural high-frequency dispersion from 4″ polypropylene driver
Installation & Construction
- Lightweight enclosure – no additional drywall support required
- Input via 2-pole terminal strip for easy wiring
- Daisy-chain wiring capability
- Press-fit grille blends with contemporary architecture
- Tile bridge included for secure ceiling mounting
Specifications:
- Speaker Type: Single Cone
- Power Taps: 1, 2, 4, 8, 16 Watts & 8Ω
- Sensitivity: 87dB Average
- Frequency Response: 100Hz – 12kHz
- Dispersion: 130°
- Depth: 7 1/8″ (18.0975 cm)
- Diameter: 7 3/8″ (18.7325 cm)
- Shipping Weight: 8.50 lbs (3.86 kgs)
- Certified Safety Listing: UL 1480
Datasheet:
